Mb

Pumps Centrifugal Monoblock

Characteristics

16 - 50m
Max. head

9 - 60m³/h
Max. flow

0.55 - 5.5kW
Motor power

1¼" - 3"
Discharge size

Application

MB pumps are suitable for pumping clean water not containing abrasive particles and fluids which are not chemically aggressive to the components of the pump. Reliable, economical and simple to use, suitable for domestic and irrigating gardens.

Installation

The pump should be installed in an enclosed environment or sheltered from inclement weather.

Materials

Pump body cast iron, radial turbine centrifugal cast brass or noryl reinforced with fiberglass.

Pumped liquid

Clean water.
Max. liquid temperature: 35°C.

Motor

Externally ventilated. Protection IP44. Class F insulation.

Features

Max. starts/hour: 30

Performance

Specification

Serie Kw Power Capacitor Passage DNC QMax HMax Palette
